TP316L ASTM A269 ASME SA269 Paslanmaz Boru 10 * 0.65 * 6000mm Parlak Tavlı
Product Details
| Malzeme: | TP304 / 304L / 304H, TP310S / 310H, TP316L / 316H / 316Ti, TP317 / 317L, TP321 / 321H, TP347 / 347H | Bitiricilik: | Tavlanmış ve Turşu / Parlak Tavlanmış |
|---|---|---|---|
| Uygulama: | kazan, enerji, petrokimya, madencilik, gıda, kağıt, gaz ve sıvı endüstrisi | şekil: | Yuvarlak sorunsuz |
| Dış çap: | 6mm ila 76mm | duvar kalınlığı: | 0,15 mm ila 4 mm |
| Vurgulamak |
ss dikişsiz borular,paslanmaz çelik kazan borusu |
||
Product Description
| STANDART: | ASME SA269 , ASTM A269 , ASME SA789 ,ASTM A 789 ,EN10216-5 , DIN17458, GOST 9941-81 | SINIF: | TP304/304L/304H , TP310S/310H, TP316L/316H/316Ti ,TP317/317L , TP321/321H, TP347/347H 904L , , SAF2507, S31803, S32750, S32760 |
|---|---|---|---|
| OD: | 1/4"(6.35), 3/8"(9.52), 1/2" (12.7), 5/8"(15.88), 3/4" (19.05), 1"(25.4) , 1-1/ 4"(31.75), 1-1/2"(38.1), 2" (50.8), 2-1/2"(63.5) , 3" (76.2),4"(101.6) | AG: | 0.89,1.2,1.5,2.11MM... |
| L: | 12ft (3657.6), 15ft (4572), 16ft (4876.8), 6m , 20ft (6096), 24ft(7315.2) ,30ft (9144) |
Product Highlights
Paslanmaz Çelik Dikişsiz Boru Turşulanmış ve Tavlanmış ASTM A269 / ASME SA269 TP316L Boyut:10*0.65*6000mm STANDART: ASME SA269 , ASTM A269 , ASME SA789 ,ASTM A 789 ,EN10216-5 , DIN17458, GOST 9941-81 SINIF: TP304/304L/304H , TP310S/310H, TP316L/316H/316Ti ,TP317/317L , TP321/321H, TP347/347H 904L , ...
Yüksek Frekanslı Kaynak Özelleştirilmiş Kömür Yakıtlı Buhar Kazanı Parçaları Yığın Ekonomizer Bobini
High Frequency Welding Customized Coal Fired Steam Boiler Parts Stack Economizer Coil Boiler economizer Boiler Economizer is the energy improving device that helps to reduce the cost of operation by saving the fuel. The economizer in Boiler tends to make the system more energy efficient. In boilers, economizers are generally designed to exchange heat with the fluid, generally water. The exhaust from the boilers is generally in the temperature range of 200°C – 250°C, so there
Ekonomizör Isı Transferi İçin Yüksek Frekanslı Kaynak Kazanı Spiral Fin Borusu
High Frequency Welding Boiler Spiral Fin Tube For Economizer Heat Transfer Boiler economizer Boiler Economizer is the energy improving device that helps to reduce the cost of operation by saving the fuel. The economizer in Boiler tends to make the system more energy efficient. In boilers, economizers are generally designed to exchange heat with the fluid, generally water. The exhaust from the boilers is generally in the temperature range of 200°C – 250°C, so there are a huge
Yardımcı Güç Santrali Tesisi İçin Eşanjör H Tipi Kazan Parçaları Borusu
High Efficient Heat Exchang H Type High Temperature Resistance Boiler Parts For Utility/Power Station Plant Product Introduce H-fin Tubes have two steel discs,with fluorescent tubes symmetrically welded together to form fins(fins of butterfly piece)creating a shape that looks somewhat like the letter"H",creating an efficient energy saving, extension heating surface.H-fin Tubes also have a high rate of fusion welds and weld tensile strength.H-fin Tube is assembled with the H
Endüstriyel Santral Kazanı İçin Uzatma Isıtma Yüzey Kazanı Fin Borusu
Energy Saving Extension Heating Surface Boiler Fin Tube For Industrial Power Plant Boiler Product Description H-fin Tubes have two steel discs,with fluorescent tubes symmetrically welded together to form fins(fins of butterfly piece)creating a shape that looks somewhat like the letter"H",creating an efficient energy saving, extension heating surface. H-fin Tubes also have a high rate of fusion welds and weld tensile strength.H-fin Tube is assembled with the H economizer,
