Eşanjör Kazan Çelik Boru Standart DIN2391 ST37.4 NBK 12 * 1MM
Product Details
| Ürün adı: | Karbon Çelik Kazan Borulu Eşanjör Dikişsiz Boru | Uygulama: | Kazan Eşanjörü |
|---|---|---|---|
| Standart: | DIN2391 | Malzeme: | ST37.4, ST52.4 |
| Vurgulamak |
DIN2391 ST37.4 NBK Çelik Boru,DIN2391 ST37.4 Eşanjör Borusu,ST37.4 NBK Kazan Çelik Borusu |
||
Product Description
Karbon Çelik Kazan Borulu Eşanjör Dikişsiz Boru DIN2391 ST37.4 NBK 12 * 1MM
Karbon Çelik Kazan Borulu Eşanjör Dikişsiz Boru DIN2391 ST37.4 NBK 12 * 1MM
DIN2391 Hassas Soğuk Çekilmiş Dikişsiz Borular ve Borular, Gr St35 St45 St52 St37.4, Hidrolik ve Pnömatik için Soğuk Bitmiş Dikişsiz Boru kullanımı.
Teslimat Durumu: NBK (+ N) BKW (+ LC) GBK (+ A) BKS (+ SR) BK (+ C) OD x WT = 4 ~ 120 x 0.5 ~ 15mm
DIN2391 St52.4 + N Fosfatlı Hidrolik Boru
atmosfer.
| Çelik sınıfı |
Kimyasal bileşim,
kütlece yüzde olarak
|
|||||
| Sembol |
Malzeme
numara
|
C maks. | Si max. | Mn |
P
maks.
|
S
maks.
|
| St 30 Si | 1.0211 | 0.10 | 0.30 | <= 0.55 | 0.025 | 0.025 |
| St 30 Al | 1.0212 | 0.10 | 0.05 | <= 0.55 | 0.025 | 0.025 |
| St 35 | 1.0308 | 0.17 | 0.35 | <= 0.40 | 0.025 | 0.025 |
| St 45 | 1.0408 | 0.21 | 0.35 | <= 0.40 | 0.025 | 0.025 |
| St 52 | 1.0580 | 0.22 | 0.55 | <= 1.60 | 0.025 | 0.025 |
|
Aşağıdaki alaşım elementleri eklenebilir:
Nb: <=% 0,03;Ti: <=% 0,03;V: <=% 0,05;Nb + Ti + V: <=% 0,05.
|
||||||
| Çelik sınıfı | Kimyasal bileşim(%): | ||||||
| Çelik adı | Çelik numarası | C max | Si max | Mn | P max | S max | Al min |
| E215 | 1.0212 | 0.10 | 0.05 | 0.70 | 0.025 | 0.025 | 0.025 |
| E235 | 1.0308 | 0.17 | 0.35 | 1.20 | 0.025 | 0.025 | - |
| E355 | 1.0580 | 0.22 | 0.55 | 1.60 | 0.025 | 0.025 | - |
