Soğuk Haddelenmiş Veya Sıcak Haddelenmiş Paslanmaz Çelik Levha Kalınlığı 6 - 80mm Q235 Q345 B C D E
Product Details
| Ürün adı: | Alaşımlı Çelik Levha | Standart: | AISI, ASTM, BS, DIN, JIS |
|---|---|---|---|
| Uygulama: | Gemi Plakası | teknik: | soğuk haddelenmiş / Sıcak haddelenmiş |
| Vurgulamak |
basınçlı kap plakası,gemi çelik plakası |
||
Product Description
Q235 Q345 BCDE soğuk haddelenmiş / sıcak haddelenmiş alaşımlı çelik levha kalınlığı 6 - 80mm
Q345B / C / D / E
1) Standart: GB
2) kalınlığı: 6-80mm
3) En: 1600-3200mm
4) Uzunluk: 6000-14000mm
5)) Yüksek kalite düşük fiyat
Kimyasal Bileşen (% WT)
| C | Si | Mn | P | S | V | Nb | Al | Ti | |
| Q345A | ≤0.20 | ≤0.55 | 1,00-1,60 | ≤0.045 | ≤0.045 | 0,02-0,15 | 0,015-0,060 | - | 0.02-0.20 |
| Q345B | ≤0.20 | ≤0.55 | 1,00-1,60 | ≤0.040 | ≤0.040 | 0,02-0,15 | 0,015-0,060 | - | 0.02-0.20 |
| Q345C | ≤0.20 | ≤0.55 | 1,00-1,60 | ≤0.035 | ≤0.035 | 0,02-0,15 | 0,015-0,060 | ≥0.015 | 0.02-0.20 |
| Q345D | ≤0.18 | ≤0.55 | 1,00-1,60 | ≤0.030 | ≤0.030 | 0,02-0,15 | 0,015-0,060 | ≥0.015 | 0.02-0.20 |
| Q345E | ≤0.18 | ≤0.55 | 1,00-1,60 | ≤0.025 | ≤0.025 | 0,02-0,15 | 0,015-0,060 | ≥0.015 | 0.02-0.20 |
Mekanik Özellikler
| kalınlık | test sıcaklığı (° c) | Uzama (%) | dayanıklı stres (Mpa) | Çekme kuvveti (Mpa) | |
| Q345A | ≤16 | - | 21 | 345 | 470-630 |
| Q345B | ≤16 | 20 | 21 | 345 | 470-630 |
| Q345C | 16-35 | 0 | 22 | ≥325 | 470-630 |
| Q345D | 35-50 | -20 | 22 | ≥295 | 470-630 |
| Q345E | 50-100 | -40 | 22 | ≥275 | 470-630 |
Bizim ürünlerimiz
| Ürün Serisi | Yönetici Standart | sınıf | Sınıf | Kalınlık (mm) |
teslim Durum |
| Düşük alaşımlı yapı çeliği | GB / T 1591-2008GB / T 3274-2007 | Q345 | A, B, | 6 ~ 150 | AR |
| CD | 6 ~ 150 | CR | |||
| E | 6 ~ 150 | TMCP | |||
| Q390 | A, B, C, D, E, | 6 ~ 150 | CR | ||
| Q420 | 6 ~ 150 | TMCP | |||
| Q500 | 6 ~ 100 | TMCP | |||
| Q550 | 6 ~ 100 | ||||
| Q620 | 6 ~ 80 | ||||
| Q690 | 6 ~ 80 | ||||
| GB / T 28410-2012 | Q235FT | B, C, D, E, | 5 ~ 150 | AR, CR | |
| Q275FT | C, D, E, F, | 5 ~ 150 | AR, CR | ||
| Q345FT | C, D, E, F, | 5 ~ 150 | AR, CR | ||
| Q420FT | C, D, E, F, | 5 ~ 150 | AR, CR | ||
| Q460FT | C, D, E, F, | 5 ~ 150 | AR, CR | ||
| EN 10025-4: 2004 | S275M / ML | - | 6 ~ 60 | TMCP | |
| S355M / ML | |||||
| S420M / ML | |||||
| S460M / ML | |||||
| JIS G3106: 2008 |
SM400 SM490 |
ABC | 6 ~ 150 | AR | |
| ABC | 6 ~ 150 | CR | |||
| YA, YB | |||||
| SM520 | M.Ö | 6 ~ 80 | TMCP | ||
| SM570 | 6 ~ 80 | ||||
| ASTM A572 / A572M-12 | Gr42 | - | 6 ~ 150 | AR | |
| GR50 | - | 6 ~ 100 | CR | ||
| Gr55 | - | 6 ~ 100 | |||
| Gr60 | - | 6 ~ 80 |
TMCP |
