TUV GB5310 Galvanizli Karbon Çelik Dikişsiz Boru
Product Details
| Ürün adı: | Kazan Borusu | Standart: | Çince GB5310 |
|---|---|---|---|
| Uygulama: | ısıtma-boru hatları, konteynerler, kömür tasarruf cihazları süper ısıtıcıları ve yeniden ısıtıcıları | Ana çelik boru sınıfı: | 20G 、 25MnG 、 15MoG 、 15CrMoG 、 12Cr2MoG 、 12Cr1MoVG |
| Malzeme: | Karbon çelik | Liman: | shanghai |
| Vurgulamak |
galvanizli karbon çeliği dikişsiz boru,GB5310 karbon çeliği dikişsiz boru,TUV karbon çeliği dikişsiz boru |
||
Product Description
Korozyona Dirençli Galvanizli Karbon Çelik Dikişsiz Boru ve Boru
Ürün Detayları
Kimyasal Bileşim ve Mekanik Özellik:
| Standart | Derece | Kimyasal bileşim(%) | ||||||
| C | Mn | Si | V | Cr | Pzt | PS | ||
| GB5310 | 20G | 0.17 ~ 0.24 | 035 ~ 0.65 | 0.17 ~ 0.37 | / | / | / | ≤ 0,030 |
| 25MnG | 0.22 ~ 0.30 | 0.70 ~ 1.00 | 0.17 ~ 0.37 | / | / | / | ≤ 0,030 | |
| 15MoG | 0.12 ~ 0.20 | 0.40 ~ 0.80 | 0.17 ~ 0.37 | / | / | 0,25 ~ 0,35 | ≤ 0,030 | |
| 15CrMoG | 0.12 ~ 0.18 | 0.40 ~ 0.70 | 0.17 ~ 0.37 | / | 0.80 ~ 1.10 | 0.40 ~ 0.55 | ≤ 0,030 | |
| 12Cr2MoG | 0,08 ~ 0,15 | 0.40 ~ 0.70 | ≤ 0,50 | / | 2,00 ~ 2,50 | 0,90 ~ 1,20 | ≤ 0,030 | |
| 12Cr1MoVG | 0,08 ~ 0,15 | 0.40 ~ 0.70 | 0.17 ~ 0.37 | 0.15 ~ 0.30 | 0,90 ~ 1,20 | 0,25 ~ 0,35 | ≤ 0,030 | |
| Mekanik Özellik | Çekme Dayanımı (Mpa) | Akma Dayanımı (Mpa) | Uzama(%) | |||||
| 20G | 410 ~ 550 | 245 | ≥ 24 | |||||
| 25MnG | 415 | ≥ 240 | ≥ 22 | |||||
| 15MoG | 450 ~ 600 | 270 | ≥ 22 | |||||
| 15CrMoG | 440 ~ 640 | 235 | ≥ 21 | |||||
| 12Cr2MoG | 450 ~ 600 | ≥ 280 | ≥ 20 | |||||
| 12Cr1MoVG | 470 ~ 640 | 255 | ≥ 21 | |||||
Product Highlights
Korozyona Dirençli Galvanizli Karbon Çelik Dikişsiz Boru ve Boru Ürün Detayları Emtia sıcak daldırma ve ön galvanizli çelik boru OD 10-600mm (yuvarlak) kalınlık 1,2-30 mm uzunluk 3-12m veya müşterilerin gereksinimlerine göre malzeme Q195 — Sınıf B, SS330, SPC, S185 Q215 — Derece C, CS Tip B, SS330, ...
